•Nominal Voltage: 25.6V

•Capacity: 180Ah

•Energy Storage: 4608Wh

•Chemistry: Lithium Iron Phosphate (LFP)

•Cycle Life: >3000 cycles at 80% DOD

•Charging Voltage: 29.2V ± 0.2V

•Discharge Cut-off Voltage:20V

•Maximum Continuous Discharge Current: 150A

•Peak Discharge Current: 360A (5 seconds)

Operating Temperature:

•Charge: 0°C to 45°C

•Discharge: -20°C to 60°C

•Storage Temperature: -20°C to 45°C

•Dimensions:600mm (L) x 300mm (W) x 150mm (H)

•Weight: 48kg

Protection Features:

•Overcharge Protection: Yes

•Overdischarge Protection: Yes

•Short Circuit Protection: Yes

•Temperature Protection: Yes

•Cell Balancing: Yes

•Connectors: Anderson or customer specified

•Warranty: 3 years limited warranty

•Recreational Vehicles (RVs)

•Boats and Marine Applications

•Solar Energy Systems

•Off-Grid Power Storage

•Telecommunication Systems

•Backup Power Supplies

•Portable Power Stations

•Installation:

Ensure the battery is installed in a well-ventilated area and away from direct sunlight. Follow the provided installation guide for proper connection and mounting.

•Maintenance:

The LFP battery requires minimal maintenance. Regularly check the connections for tightness and inspect the battery for any signs of damage or wear.

•Charging:

Use a compatible lithum battery charger with a maximum charging current of 50A. Ensure the charger is set to the recommended charging voltage (14.6V ± 0.2V).

•Handling:

Handle the battery with care to avoid dropping or damaging it.

•Ventilation:

Ensure adequate ventilation during charging and discharging to prevent the accumulation of gases.

•Temperature:

Avoid exposing the battery to extreme temperatures.

•Electrical Connections:

Ensure all electrical connections are secure and properly insulated.

•Disposal:

Dispose of the battery according to local regulations and recycling guidelines.
